Side view of replacement wheel lean hydraulic cylinder for Caterpillar 16H/16M motor grader, OEM part number 289-3054
Top view of replacement wheel lean hydraulic cylinder for Caterpillar 16H/16M motor grader, OEM part number 289-3054
Replacement wheel lean hydraulic cylinder for Caterpillar 16H/16M motor grader, OEM part number 289-3054, aftermarket heavy equipment parts
Side view of replacement wheel lean hydraulic cylinder for Caterpillar 16H/16M motor grader, OEM part number 289-3054
Top view of replacement wheel lean hydraulic cylinder for Caterpillar 16H/16M motor grader, OEM part number 289-3054

Wheel Lean Cylinder for 16H/16M Motor Grader – AKC28930541 (Ref. Caterpillar 289-3054)

Request a Quotation

Designed to fit your equipment based on the manufacturer’s specifications.

Any changes to the manufacturer’s configuration might result in the product not fitting your equipment. Please consult us before purchasing to ensure that this part is appropriate for your equipment in its current condition and assumed configuration.

Warranty Backed Components
After Sales Support
Industry leading quality

Share this product

Got questions? Feel free to get in touch.

Portrait of Chief Operating Officer Robert McKenzie

Ask an expert!

Video chat Chat Email
Looking for spare parts?
We offer a comprehensive selection of parts like seal kits, bushings, bolts, and more. Get in touch to learn more.
Machine type Motor Grader
Machine brand* Caterpillar
Compatible models* 16H, 16M
Cylinder type Wheel Lean
Weight (kg) 29.75
Maximum working pressure (bar) 240.0
Stroke length (mm)
174.8
Pin to pin length (mm)
543.1
Akaliko part number(s) AKC28930541
OEM part number(s)* 289-3054
HS code 841221

Pin to pin length

Diagram showing the pin-to-pin length measurement.

Pin to pin length is measured center-to-center between the mounting pin bores.

Stroke length

Diagram showing the stroke length measurement.

Stroke length is the difference between the fully extended and fully retracted length of the cylinder.

*References to the OEM are for identification purposes only. These aftermarket components are not manufactured, endorsed, or affiliated with the OEM.

The warranty period is 12 months from the delivery date or 5000 operating hours. The warranty covers defects in material and workmanship throughout the warranty period. For complete warranty details, please contact us directly.
